PolyWorks GD&T Training Course

2 Day Course | £750 | ISO 1101

2 Day Course | £750 | ISO 1101

Our 2-day PolyWorks GD&T course is designed for users with existing GD&T knowledge, providing practical, hands-on training to apply GD&T principles effectively within PolyWorks.

PolyWorks GD&T Training from the UK Master Reseller

Delivered by the UK and Ireland Master Reseller for PolyWorks, the training is led by experts with extensive experience in PolyWorks software and industrial metrology. Designed for engineers, metrologists, and quality professionals with existing GD&T knowledge, this course provides the practical skills to create, apply, and analyse GD&T within PolyWorks, enabling more accurate inspections and greater confidence in your measurement results.

Training Agenda

Our PolyWorks GD&T training course is meticulously designed to cover all essential aspects. The agenda includes:

GD&T Help and Information in The PolyWorks® Software

• PolyWorks® Inspector Options – GD&T and Dimensional Controls. • ISO Standard GD&T in PolyWorks®.

Size Tools

Form Tools

Orientation Tools

Location Tools

Modifiers

Composite Datum Features

Datum Features, Datum Targets, Datum Reference Frames and DRF Alignments

GD&T Results Analysis

Learning Outcomes

By the end of our PolyWorks GD&T training course, participants will achieve the following learning outcomes:

PolyWorks & ISO Standards

Understand PolyWorks Options for the ISO Standards and how it interacts with them.

Navigating PolyWorks GD&T

Using the GD&T Interface

Understanding GD&T Fundamentals

Creating GD&T Controls

Applying GD&T Modifiers

Creating Composite Datums

Working with Datums & Reference Frames

Analysing GD&T Results

Get a GD&T training

quote today

Get a GD&T training

quote today

Fill in the form with your preferred course and how many of you are coming, and one of our team will be in touch shortly.
